SX3-1020A-QB-US QuickBridge, Pair of Stratum SX3-1020A-US X3 5GHz All-purpose Units preconfigured as QB, MIMO 2x2, 1Gbps, 2x RP-

Name: SX3-1020A-QB-US QuickBridge, Pair of Stratum SX3-1020A-US X3 5GHz All-purpose Units preconfigured as QB, MIMO 2x2, 1Gbps, 2x RP-
Brand: Proxim Wireless
SKU: 907-00019
Price: 3450 USD
Availability: InStock

Fabricante Proxim Wireless

Número de parte 907-00019

3 In Stock

Tipos de producto: Módulo de radio PtP

Características del producto: Exterior | FCC | Hasta 1 Gbps

Frecuencias: 4.9-5.8 GHz | 5.2 GHz | 5.4 GHz | 5.8 GHz

3.450,00 $

Inicie sesión para ver su mejor precio

Los precios pueden estar sujetos a aranceles.

Últimas unidades en stock

Obtenga el equipo que su empresa necesita con LEAF.

1-888-946-6266 EXT 146 / sales.CALA@winncom.com

Disponible de lunes a viernes, de 8:00 a. m. a 5:00 p. m. (EST).

Stratum[tm] X3 5GHz

The Stratum X3 - 5GHz is a high-performance MIMO 2x2 point-to-point solution capable of throughput up to 1Gbps. The Stratum X3 is an excellent long-range backhaul solution.

Both integrated and external antenna options are available and enable long-range high-capacity secure over the air Ethernet transmission.

* Throughput up to 1Gbps

* Wide Band Radio - 5.150-5.850 GHz

* Triple 1Gbps Ethernet with POE in and out

* AES 128-bit encryption is upgradeable to 256-bit

* 20, 40 and 80 MHz channels.

* Full tilt and swivel mounting kit included

Flexible Antenna Options

The SX3-1021A is a flexible variant that includes an integrated dual polarity panel antenna, plus software selectable connectors for external antennas.

Model SX3-1020A is a connectorized unit purpose build for external dual polarity antennas where specific antenna patterns or gain adjustments are needed.

Advanced Interference Management

Proxim ClearConnect[tm] combines multiple dynamic technologies and delivers the best interference management solution.

Flexible and Secure Management Options

Management options include Proxim BlueConnect[tm]; our Bluetooth-enabled mobile management application; TLS 1.3 web GUI, SSH 2.0 CLI, and SNMP v3 for ProximVision Advanced or other network management solutions.

Rugged Reliability

Stratum X3 uses an IP67-rated metal enclosure to ensure years of reliable service in harsh environments, including high winds, high salt, and temperature extremes.

Ficha técnica

Tipos de producto	Módulo de radio PtP
Características del producto	Exterior \| FCC \| Hasta 1 Gbps
Frecuencias	4.9-5.8 GHz \| 5.2 GHz \| 5.4 GHz \| 5.8 GHz

Proxim_Stratum_X3_QB_DS.pdf

Descargas (378.72KB)
